| Item | Specification / Description |
|---|---|
| Material | EVA, PO, TPU and other hot melt adhesive bases |
| Color | Transparent, white, milky white, etc. |
| Thickness | 0.1 mm ~ 0.5 mm (including adhesive layer) |
| Mesh Size | 0.5 mm ~ 5 mm (customizable) |
| Width | ≤ 1500 mm (customizable) |
| Melting Point Range | 80℃ ~ 160℃ (depending on material) |
| Application Temperature | 150℃ ~ 220℃ |
| Recommended Heat Press Time | 10 ~ 30 seconds |
| Recommended Pressure | 0.2 ~ 0.6 MPa |
| Environmental Compliance | RoHS / REACH |
Applications
Footwear Industry: Lamination of uppers and linings, bonding midsoles and outsoles
Apparel Industry: Seamless garment bonding, lining and fabric lamination
Automotive Interiors: Bonding seat fabrics with foam, dashboard panel adhesion
Electronics Industry: Lightweight structural bonding for electronic products
Others: Upholstered furniture, sports goods, and various lightweight composite bonding
Instructions for Use
Preparation
Use heat press machines, roller laminators, or ironing machines with adjustable temperature and pressure.
Ensure bonding surfaces are clean, dry, and free from dust and oil.
Application
Place the hot melt adhesive net between the two substrates to be bonded.
Perform heat pressing with recommended temperature, pressure, and time settings.
Cooling and Curing
After pressing, allow the materials to cool to room temperature for complete curing of the adhesive layer.
Notes
Conduct preliminary tests to determine optimal parameters for different materials.
Avoid excessive temperature that could burn the adhesive net or deform substrates.
Store in a cool, dry place away from direct sunlight.
