| Item | Specification / Description |
|---|---|
| Material | EVA Copolymer |
| Appearance | Transparent or Milky Film |
| Thickness | 0.03 mm ~ 0.5 mm (customizable) |
| Width | Up to 1600 mm (customizable) |
| Melt Flow Index | 5 ~ 15 g/10min |
| Softening Point | 75℃ ~ 90℃ |
| Recommended Heat Press Temperature | 90℃ ~ 140℃ |
| Recommended Heat Press Time | 5 ~ 25 seconds |
| Recommended Heat Press Pressure | 0.2 ~ 0.6 MPa |
| Tensile Strength | ≥ 15 MPa |
| Elongation at Break | ≥ 400% |
| Environmental Compliance | RoHS / REACH |
Applications
Packaging Industry: Food packaging films, heat sealing films, moisture barrier packaging
Footwear Industry: Lamination of shoe uppers and linings
Textile Industry: Heat bonding of garments and composite fabrics, upholstery lamination
Solar Industry: Encapsulation films for photovoltaic modules
Others: Stationery, toys, automotive interior laminations, and other composite applications
Instructions for Use
Preparation
Use appropriate heat press equipment such as heat press machines, ironing machines, or roller presses.
Ensure bonding surfaces are clean, dry, and free of grease or dust.
Heat Press Process
Place EVA adhesive film between two substrates to be bonded.
Set suitable temperature, pressure, and time according to product parameters.
Cooling and Curing
After heat pressing, allow the bonded materials to cool to room temperature to ensure full curing and optimal bonding strength.
Notes
Perform small sample tests with different materials to determine optimal parameters.
Avoid excessive temperature to prevent film aging or discoloration.
Store in a cool, dry place away from direct sunlight.
